Cottage JM Stugor & Fritid The Folk Cottage
20 m2, Effective thickness 90 mm
Carcass/wood thickness
Knotted timber 90 x 130 mm, also available in 44 and 60 mm timber thickness
The holiday home "Folkstugan" has a smart floor plan with a practical and cosy loft. Folkstugan gives you a nice cottage with three rooms of different sizes that you can, for example, furnish as a living room / large cottage + bedroom + kitchen / pantry or kitchen / lounge + office + WC / bath / shower.
Windows & doors
- Openable windows: 2-glazed insulating glass windows (depending on choice). U-value 2.6. Optional: glazing bars, 3-glazed U-value 1.1
- 1 pcs. Double glazing 1400 x 1000 mm, 3 pcs. Window 760 x 1000 mm, 1 pc. Double glazing 1400 x 1000 mm, 3 pcs. Staircase ladder to loft: 1 included Not included: Roof cladding, battens, insulation, screws and nails
20 m2, Effective thickness 90 mm
Carcass/wood thickness
Knotted timber 90 x 130 mm, also available in 44 and 60 mm timber thickness
The holiday home "Folkstugan" has a smart floor plan with a practical and cosy loft. Folkstugan gives you a nice cottage with three rooms of different sizes that you can, for example, furnish as a living room / large cottage + bedroom + kitchen / pantry or kitchen / lounge + office + WC / bath / shower.
Windows & doors
- Openable windows: 2-glazed insulating glass windows (depending on choice). U-value 2.6. Optional: glazing bars, 3-glazed U-value 1.1
- 1 pcs. Double glazing 1400 x 1000 mm, 3 pcs. Window 760 x 1000 mm, 1 pc. Double glazing 1400 x 1000 mm, 3 pcs. Staircase ladder to loft: 1 included Not included: Roof cladding, battens, insulation, screws and nails
Addons
Option Front door
Extra Timber Yard
Usually, you add one or more extra layers of timber if you intend to insulate your cottage, for example the internal roof, in which case a slightly higher roof height may be appropriate. But it is just as possible to insulate the roof from the outside from above, either way, depending on whether you want visible ridges in the inner roof or panelling.
Window bars
Specification
| Weight | Width | Height | Length | Roof pitch | Roof bearing capacity | mute | Floor | Tak | House type | Building area | Material (wood).1 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 3500 kg | 3,8 m | 3,6 m | 5,2 m | 30 degrees (optional) | 220 kg/sqm (depending on timber thickness & ridges) | Planed and knotted wall profiles, 60 x 130 or 90 x 130 mm | 28 mm finely planed on floor joists 60 x 140/160/180 mm | 19 mm x 100 mm planed raw fibreboard on roof ridges 60 x 160/180 mm | knot-timbered loft cabin, any timber thickness 44, 60 or 90 mm (walls) | 20 square metres | latewood Nordic spruce, untreated and unpainted wood |
Package Dimensions
| Width | Height | Depth | Volume | Weight |
|---|---|---|---|---|
| N/A | N/A | N/A | N/A | 3500kg |
